DIN 787

SK: Skrutka pre T-drážky
EN: T-slot bolt
DE: Schraube für T-Nuten

Standards: DIN 787

DIN 787 – Technical drawing

Available sizes:

a	d	l – b	e	k	DIN 650	Lengths l in stock (mm)
6	M 6	–	10 – 0,5	4 – 0,5	6
8	M 8	–	13	6	8	32, 40, 50
10	M 10	–	15	6	10	40, 50, 65
12	M 12	200 – 120	18	7	12	40, 50, 65, 80, 100, 125
14	M 12	200 – 120	22	8	14
18	M 16	250 – 150	28	10	18
22	M 20	–	35	14	22
28	M 24	–	44 – 1	18 – 1	28
